Product Description

IPM320/C

Worktable size : 460*740 mm

X-Y Stroke : 320*400mm

Cutting thickness : 280mm

Taper angle : ±6

Cutting Speed :  200mm2/min

Driving motor : Stepper motor

Machine weight : 2450KG

Overall size : 1700*1250*2150mm

Wire diameter : 0.12-0.20mm

Wire running speed : 11.SH(adjustable)m/s

Cutting accuracy : 0.008mm

Maximum current : 12A

Power supply : 3 Phase 380V

Pulley : Black Diamond

Pulley bearing : NSK

Water nozzle : Rubine Diamond

Oil pump : Automatic oiling

IPM400fC

Worktable size :  540*840mm

X-Y Stroke : 400*500mm

Cutting thickness : 280mm

Taper angle : ±6

Cutting Speed :  200mm2/min

Driving motor : Stepper motor

Machine weight : 2650KG

Overall size : 1960*1620*2160mm

Wire diameter : 0.12-0.20mm

Wire running speed : 11.SH(adjustable)m/s

Cutting accuracy : 0.008mm

Maximum current : 12A

Power supply : 3 Phase 380V

Pulley : Black Diamond

Pulley bearing : NSK

Water nozzle : Rubine Diamond

Oil pump : Automatic oiling

IPMSOO

Wire Cut Machine : 640*1020mm

X-Y Stroke : 500*630mm

Cutting thickness : 350mm

Taper angle : ±6

Cutting Speed : 200mm2/min

Driving motor : Stepper motor

Machine weight : 3150KG

Overall size : 2120*1760*2320mm

Wire diameter : 0.12-0.20mm

Wire running speed : 11.SH(adjustable)m/s

Cutting accuracy : 0.008mm

Maximum current : 12A

Power supply : 3 Phase 380V

Pulley : Black Diamond

Pulley bearing : NSK

Water nozzle : Rubine Diamond

Oil pump : Automatic oiling

IPM630

Worktable size : 750*1180mm

X-Y Stroke : 630*800mm

Cutting thickness : 350mm

Taper angle : ±6

Cutting Speed :  200mm2/min

Driving motor : Stepper motor

Machine weight : 4200KG

Overall size : 2430*2060*2350mm

Wire diameter : 0.12-0.20mm

Wire running speed : 11.SH(adjustable)m/s

Cutting accuracy : 0.008mm

Maximum current : 12A

Power supply : 3 Phase 380V

Pulley : Black Diamond

Pulley bearing : NSK

Water nozzle : Rubine Diamond

Oil pump : Automatic oiling

IPM800

Worktable size : 1050*1420mm

X-Y Stroke : 800*1000mm

Cutting thickness : 350mm

Taper angle : ±6

Cutting Speed :  200mm2/min

Driving motor : Stepper motor

Machine weight : 5650KG

Overall size : 2650*2250*2530mm

Wire diameter : 0.12-0.20mm

Wire running speed : 11.SH(adjustable)m/s

Cutting accuracy : 0.008mm

Maximum current : 12A

Power supply : 3 Phase 380V
