Features

■ Direct access to more than 200 tests through test keys

■ Maintenance free peristaltic pump

■ Unique circuitry for long lamp life

■ Triple cuvette system

■ Real time graph with online reading

■ Multi standard calibration & memory

■ Automatic calibration against standard

■ Displays actual temperature on screen

■ Levey jennings and standard deviation graphs

■ Sample carry over prevention facility

■ Robust system with built in stabilizer

■ Patient report with PIO & name

■ User friendly software

■ USB interface

Technical Specifications

OPTICAL SYSTEM

Linear measurement range : 0.000 to 3.000 absorbance units (A)

Photometric accuracy : ± 2 % or 0.007 whichever is higher,

from O to 1.5 A, ± 3 % from 1.5 A to 3.0 A

Optical measurement : Photodiode

Light Source : Tungsten halogen

FILTERS

Type of filter : High quality narrow band interference

Wave length : 340, 405, 510, 546, 578, 630 nm & two optional

FLOW CELL

Sipping volume : upto 1000 μI

Triple cuvette system : 18 μI flow cell

MEMORY

Open tests : 250 tests

10 mm square cuvette

Round tube for coagulation

Results : 2500 patient results

QC : 30 QC results/test

INCUBATOR: 15 Positions at 37°

ANALYSIS MODES

Biochemistry & Turbidimetry : Absorbance, End Point, Fixed Time,

Kinetic, Differential & Ratio

Coagulation : PT, INR & APTT

DISPLAY

Human machine interface : TOUCH PANEL/ KEYPAD

5" Color Graphics LCD

PRINTER : On board thermal 28 columns, maintenance free

POWER

Wattage: 100 VA

Voltage : 115 - 230 Volts ± 10%, 50 - 60 Hz

STORAGE CONDITIONS

Temperature : From - 10°C to + 60°C

Relative humidity : Up to 85%

Enclosure : ABS fire retardant

Dimensions in mm (lxbxh) : 380 x 305 x 175 (Approx)

Weight : 5 kgs. (Approx)
