Features

COAGULATION

■Four independent programmable coagulation channels for faster throughput.

■Display online results of all four channels simultaneously on single screen.

■Designed to perform all routine & special tests such as PT, APTT, TT, Fibrinogen, Factor II, V, VII, VIII, IX, X, XI, XII.

Uniform mixing of Sample & Reagent with magnetic stirrer.

■Automatic sensing of sample/reagent dispensing to start the measurement.

Multipoint Calibration curve with user entered standard dilution % in FIB and Factor Assay.

PHOTOMETER:

Independent channel for Photometric assays.

Multipoint calibration curve with maximum 7 calibrators for Photometric assays.

■Chromogenic assays antithrombin III (AT-III), protein C (PC), protein S (PS), D-dimer.

COMMON:

Effective temperature regulation system.

Robust system with built in stabilizer.

■Storage Capacity of 250 open tests with QC and more than 2500 results.

■Independent memory for Coagulation and Photometric mode.

Unique circuitry for long lamp life.

■Human machine interface: Touchpad, Keypad.

Quality Control with Levey Jennings and standard deviation graphs.

Technical Specifications

COAGULATION

Measuring System: Photometric/Mechanical

Optical Measurement: Photodiode

Measuring Volume: 150 µl

Sample & Reagent Mixing: With Magnetic Stirrer

Dry Block Incubator: 24 Positions Temperature at 37°c

Light Source: LED

Analysis Mode: PT, APTT, TT, Fibrinogen, Factor Assay (Factor II, V, VII, VIII, IX, X, XI, XII)

Results Displayed in: Seconds, Ratio, INR, Concentration and %

PHOTOMETER:

Linear Measurement Range: 0.000 to 3.000 Absorbance Units (A)

Photometric Accuracy: ± 2% or 0.007 Whichever is Higher, From 0 to 1.5 A, ± 3% from 1.5 A to 3.0 A

Optical Measurement: Photodiode

Cuvette Volume: 500 µl

Filters Interference: 405, 630 nm

Light Source: Tungsten Halogen

Warm Up Time: 90 Seconds

Analysis Mode: Absorbance, Kinetic, End Point, Fixed Time

COMMON:

Computer Interface: RS 232 Serial Port

Power: 50 Watts/115-230 Volts ± 50/60 Hz

Operating Position: On Horizontal Flat, Rigid and Vibration Free Surface : USB

Operating Conditions: Operating Conditions

Temperature: From + 18° C to 35°C

Relative Humidity: Up to 85%

Dimensions in mm (lxbxh): 345 X 300 X 140 (Approx)

Weight: 5.4 kg (Approx)
