Product Details
walls of the room will be constructed with solid bricks with cement plastering. Operation Theater Wall, Sloping, Risers and Ceiling The wall panels will be constructed using both side PPGI/EGP sheet and with core consisting of rigid polyurethane foam, which has been injected under high pressure, with a minimum density of 40 kg/m3. The gaps between panels shall be suitably filled with metal filler/epoxy and sanded flush.
Features:
All the sharp edges and corners will be in radius to avoid bacteria contamination. The internal surfaces of the room walls will be sprayed with water based liquid plastic, wall glaze or equivalent, approved by the architect to a minimum dry film thickness of 300 microns. The plastic coating will overlap the floor covering, ceiling system and doorframes by 25 microns to provide a continuous sealed surface. The plastic coating will be nonreflective and the color will be submitted to the architect for approval.
Ceiling System Design
• Metal ceiling is made of individually detachable panels with Customize dimensions.
The substructure is made of galvanized steel Panels are fixed in clip-in system.
Surfaces
Galvanized or stainless steel, powder coated, optionally with antibacterial paint.
Standard colour is RAL 9010. Other color available optionally
Matt, washable, light resistance surface
Dust-free, abrasion-proof, corrosion resistant, non-hygroscopic.
