Features
Designed to perform all routine tests such as PT, APTT, TT,- FIB and clotting factors Results are both printed and displayed in seconds and in concentration
- Data is printed and stored with RATIO and INR values
- Dry block incubator for 37 degree centigrade with multi timer
- Uniform mixing of Sample & Reagent with magnetic stirrerAutomatic sensing of cuvette insertion
- Automatic sensing of dispensing of Reagent that triggers the reaction
- Facility to enter clinic name
- Prints and stores calibration graph.
Technical Specifications
Measuring System: Photometric
Optical Measurement: Photodiode
Cuvette Volume (Minimum): 150 μι
Sample & Reagent Mixing: With magnetic stirrer
DRY BLOCK INCUBATOR
Number of Cuvettes: 10 + 1 Test tube holder
Temperature: 37°C
Timer: 2 channels for programming incubation time
Light Source: LED
Display: Four line LCD, back lit, 4 x 20 characters
Printer: Built-in thermal printer, 28 Column
Memory: 35 Open tests
Analysis Mode: CLOT TIME, INR (PT) MULTI STD (FIB)
Results displayed in: Seconds, Ratio, INR (Automatically Calculated), Concentration
Power: 50 Watts/115-230 Volts + 50-60 Hz
Dimensions in mm (lxbxh): 300 x 215 x 150 (Approx)
Weight: 3 Kgs. (Approx)
